Thomas Stockham -
Thomas Greenway Stockham (December 22, 1933 – January 6, 2004) was an American scientist who developed the first practical digital audio recording system, and pioneered techniques for digital audio recording and processing as well.
Stockham, known as the "father of digital audio", earned an Sc. D. degree from MIT in 1959 and was appointed Assistant Professor of Electrical Engineering. While at MIT, he noticed several of the students using an MIT Lincoln Laboratory TX-0 mainframe computer installed at the campus to record their voices digitally into the computer's memory, using a microphone and a loudspeaker connected to a A/D-D/A converter attached to the TX-0. This led Stockham to his own digital audio experiments on this same computer in 1962.
In 1968 he left MIT for the University of Utah, and in 1975 founded Soundstream, Inc. The company developed a 16-bit digital audio recording system using a 16-track Honeywell instrumentation tape recorder as a transport, connected to digital audio recording and playback hardware of Stockham's design. It ran at a sampling rate of 50 kHz, as opposed to the audio CD sampling rate of 44.1 kHz.
Soundstream Inc. was the first commercial digital recording company in the United States, located in Salt Lake City. Stockham was the first to make a commercial digital recording, using his own Soundstream recorder in 1976 at the Santa Fe Opera. In 1980, Soundstream merged with the Digital Recording Company (DRC) and became DRC/Soundstream.
Dr Stockham played a key role in the digital restoration of Enrico Caruso recordings, described in a 1975 IEEE paper "Blind Deconvolution through Digital Signal Processing". These recordings were the first ever to be digitally restored by computer, and were released on the album "Caruso-A Legendary Performer" by RCA Records in 1976.
In 1974 he investigated President Richard Nixon's White House tapes.
Dr. Stockham's developments and contributions to digital audio paved the way for later digital audio technologies, such as the audio compact disc and DAT (Digital Audio Tape).
Dr Stockham received wide recognition for his pioneering contributions to digital audio. He received, among many others, the Gold Medal award from the Audio Engineering Society, a Technical Emmy award in 1988, a Grammy award from NARAS in 1994, and a Scientific and Engineering award from the Academy of Motion Picture Arts and Sciences in 1999.
-en.wikipedia.org/wiki/Thomas_Stockham
Digital Audio Tape -
Digital audio tape can also refer to a compact cassette with digital storage.
Digital Audio Tape (DAT or R-DAT) is a signal recording and playback medium developed by Sony in the mid 1980s. In appearance it is similar to a compact audio cassette, using 4 mm magnetic tape enclosed in a protective shell, but is roughly half the size at 73 mm × 54 mm × 10.5 mm. As the name suggests the recording is digital rather than analog, DAT converting and recording at higher, equal or lower sampling rates than a CD (48, 44.1 or 32 kHz sampling rate, and 16 bits quantization). If a digital source is copied then the DAT will produce an exact clone, unlike other digital media such as Digital Compact Cassette or non-Hi-MD MiniDisc, both of which use lossy data compression.
Like most formats of videocassette, a DAT cassette may only be recorded on one side, unlike an analog compact audio cassette.
History -
Development:
The technology of DAT is closely based on that of video recorders, using a rotating head and helical scan to record data. This prevents DATs from being physically edited in the cut-and-splice manner of analog tapes, or open-reel digital tapes like ProDigi or DASH.
The DAT standard allows for four sampling modes: 32 kHz at 12 bits, and 32 kHz, 44.1 kHz or 48 kHz at 16 bits. Certain recorders operate outside the specification, allowing recording at 96 kHz and 24 bits (HHS). Some machines aimed at the domestic market did not operate at 44.1 kHz when recording from analog sources. Since each recording standard uses the same tape, the quality of the sampling has a direct relation to the duration of the recording – 32 kHz at 12 bits will allow six hours of recording onto a three hour tape while HHS will only give 90 minutes from a three hour tape. Included in the signal data are subcodes to indicate the start and end of tracks or to skip a section entirely; this allows for indexing and fast seeking. Two-channel stereo recording is supported under all sampling rates and bit depths, but the R-DAT standard does support 4-channel recording at 32 kHz.
DAT tapes are between 15 and 180 minutes in length, a 120-minute tape being 60 meters in length. DAT tapes longer than 60 meters tend to be problematic in DAT recorders due to the thinner media.
Predecessor formats:
DAT was not the first digital audio tape; pulse-code modulation (PCM) was used in Japan to produce analogue phonograph records in the early 1970s, using a videotape recorder for its transport, but this was not developed into a consumer product.
Later in 1976, the first commercially successful digital audio tape format was developed by Soundstream, using 1" (2.54 cm) wide reel-to-reel tape loaded on an instrumentation recorder manufactured by Honeywell acting as a transport, which in turn was connected to outboard digital audio encoding and decoding hardware of Soundstream's own design. Several major record labels like RCA and Telarc used Soundstream's system to record some of the first commercially-released digital audio recordings.
Soon after Soundstream, 3M starting in 1978 introduced their own line (and format) of digital audio tape recorders for use in a recording studio, notably the model M79, with one of the first prototypes being installed in the studios of Sound 80 in Minneapolis, Minnesota.
Professional systems using a PCM adaptor, 98'7789 /'which digitized an analog audio signal and then encoded this resulting digital stream into an analog video signal so that a conventional VCR could be used as a storage medium, were also common as mastering formats starting in the late 1970s.
dbx, Inc.'s Model 700 system, notable for using high sample-rate delta-sigma modulation (similar to modern Super Audio CDs) rather than PCM, and Decca's PCM system in the 1970s[1] (using a videotape recorder manufactured by IVC for a transport), are two more examples.
Mitsubishi's X-80 digital recorder was another 6.4 mm (¼") open reel digital mastering format that used a very unusual sampling rate of 50.4 kHz.
For high-quality studio recording, effectively all of these formats were made obsolete in the early 1980s by two competing reel-to-reel formats with stationary heads: Sony's DASH format and Mitsubishi's continuation of the X-80 recorder, which was improved upon to become the ProDigi format. (In fact, the first ProDigi-format recorder, the Mitsubishi X-86, was playback-compatible with tapes recorded on an X-80.) Both of these formats remained popular as an analog alternative until the early 1990s, when hard disk recorders rendered them obsolete.
Anti-DAT lobbying -
In the late 1980s, the Recording Industry Association of America unsuccessfully lobbied against the introduction of DAT devices into the U.S. Initially, the organization threatened legal action against any manufacturer attempting to sell DAT machines in the country. It later sought to impose restrictions on DAT recorders to prevent them from being used to copy LPs, CDs, and prerecorded cassettes. This opposition was led by CBS Records president Walter Yetnikoff, but softened after Sony, a DAT manufacturer, bought CBS Records in January 1988. By June 1989, an agreement was reached, and the only concession the RIAA would receive was a more practical recommendation from manufacturers to Congress that legislation be enacted to require that recorders have a Serial Copy Management System to prevent digital copying for more than a single generation.[2] This requirement was enacted as part of the Audio Home Recording Act of 1992.
Uses of DAT -
Professional recording industry:
DAT was widely used in the professional audio recording industry in the 1990s, and is still used to some extent today, as the archives created in the '90s are still widely used, although most labels have a program in place to transfer these tapes to a computer-based database. DAT was used professionally due to its lossless encoding, which allowed a master tape to be created that was more secure and didn't induce yet more tape noise (hiss) onto the recording. In the correct setup, a DAT recording could be created without even having to be decoded to analogue until the final output stage, since digital multi-track recorders and digital mixing consoles could be used to create a fully digital chain. In this configuration, it's possible for the audio to remain digital from the first AD converter after the mic preamp until it's in a CD player. DAT's were also frequently used by radio broadcasters. Until recently, they were still used by the BBC as an emergency broadcast that would initiate if the player detected a lack of noise continued for more than a pre-determined time. This would mean that if for any reason the broadcast from the studio stopped, the DAT would continue broadcast until normal service could be resumed.
This section requires expansion.
Amateur and home use:
DAT was envisaged by proponents as the successor format to analogue audio cassettes in the way that the compact disc was the successor to vinyl-based recordings; however, the technology was never as commercially popular as CD. DAT recorders remained relatively expensive, and commercial recordings were generally not made available on the format. However, DAT was, for a time, popular for making and trading recordings of live music, since available DAT recorders predated affordable CD recorders.
In the U.S., the RIAA and music publishers continued to lobby against DAT, arguing that consumers' ability to make perfect digital copies of music would destroy the market for commercial audio recordings. The opposition to DAT culminated in the passage of the resulting Audio Home Recording Act of 1992, which, among other things, effectively imposed a tax on DAT devices and blank media.
Computer data storage medium:
The format was designed for audio use, but through the ISO Digital Data Storage standard it has been adopted for general data storage, storing from 1.3 to 72 GB on a 60 to 170 meter tape depending on the standard and compression. It is sequential-access media and is commonly used for backups. Due to the higher requirements for capacity and integrity in data backups, a computer-grade DAT was introduced, called DDS (Digital Data Storage). Although functionally similar to audio DATs, only a few DDS and DAT drives (in particular, those manufactured by Archive for SGI workstations[3]) are capable of reading the audio data from a DAT cassette. SGI DDS4 drives no longer have audio support; SGI removed the feature due to "lack of demand"[4].
Future of DAT -
In November 2005, Sony announced that the final DAT machines would be discontinued the following month.[1] However, the DAT format still finds regular use in film and television recording, principally due to the support in some recorders for SMPTE time code synchronization, although it is slowly being superseded by modern hard disk recording equipment which offers much more flexibility and storage. In 2004, Sony introduced the Hi-MD Walkman with the ability to record in linear PCM. Hi-MD has found some favour as a disc-based DAT alternative for field recordings and general portable playback.
Archived audio problem:
The discontinuation of DAT replayer production leads to a significant problem regarding audio archives, since a tremendous amount of recordings from the mid-80's until ~2000 exist solely on DATs. This means that this material is locked up on these tapes.
Even if some bigger broadcasting stations or studios still have some of them in their internal stock or could find a handful of second hand models, each device inevitably suffers wear-out in the play heads, winding mechanism, etc.
See also:
* ADAT
* Magnetic Tape
* PCM adaptor
* Digital Audio Stationary Head
* ProDigi
Audio/video:
* Digital Compact Cassette (DCC)
* Compact Disc (CD)
* MiniDisc (MD)
* Digital Versatile Disc (DVD)
* Universal Media Disc (UMD)
* Super Audio CD (SACD)
References:
1. ^ G.Mancini (March 2004). The Decca Digital Audio Recording System. Retrieved on 2007-10-25.
2. ^ Goldberg, Michael (1989-09-21). "Labels Back Down on DAT". Rolling Stone (561): 26.
3. ^ Can you Rip DAT audio? (Ask Slashdot forum thread). Slashdot (1999-10-01). Retrieved on 2007-10-25.
4. ^ DAT/DDS hardware (2003-03-26). Retrieved on 2007-10-25.
